Overview
The UTS3000-TG adds a tracking generator swept source synchronized with the analyzer for measuring insertion loss, return loss, and frequency response of filters, amplifiers, cables, and components. The option is enabled by a software license keyed to the spectrum analyzer’s serial number and is permanent for the life of the instrument.
Key Features
- Synchronized Sweep Output tracks analyzer center frequency for stimulus-response measurements.
- Component Characterization Measure insertion loss, passband flatness, and rejection directly.
- Cable Testing Cable loss, antenna return loss, connector insertion loss across frequency.
- Normalization Reference sweep calibration removes system losses.
- Lifetime License Activation activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- Filter Testing Sweep a bandpass filter to verify center frequency, bandwidth, insertion loss, and rejection.
- Cable Loss Measure cable attenuation vs. frequency to select appropriate cables.
Compatibility
This option is compatible with all UTS3000B/T Series spectrum analyzers.
Frequently Asked Questions
How is this option activated?
The option is enabled by a software license keyed to the spectrum analyzer’s serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the spectrum analyzer from a USB drive through the option-install menu. Refer to the spectrum analyzer’s user manual for the step-by-step procedure.
Is the license permanent, or does it require renewal?
The license is permanent a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
