Overview
Replacement 5,000 mAh lithium-ion battery pack for UNI-T Inspector-series professional thermal cameras. Keep a spare charged for all-day field work the snap-on pack swaps in seconds, and the built-in OLED display shows remaining charge at a glance. For use with UNI-T UTi740X and UTi760X series thermal cameras.
Key Features
- 5,000 mAh / 36 Wh, 7.2 V Capacity Extended runtime for full-day inspection workflows.
- OLED Charge Display Built-in 0.5″ OLED screen shows exact remaining charge percentage.
- USB-C Fast Charging Up to 27 W via USB Type-C with PD 3.0, PD 3.1, and BC 1.2 support.
- Under 2.5-Hour Full Charge Fast turnaround between inspection runs.
- Independent Charging Charge the pack off-camera to keep your primary battery in the field.
- Full Protection Circuitry Overcharge, over-discharge, overcurrent, overvoltage (24 V), short-circuit, and NTC temperature protection built in.
- CE / UN 38.3 Certified Meets international lithium-battery safety and transport standards.
- Compatible with UNI-T UTi740X and UTi760X series See UNI-T professional thermal cameras for compatible models.
Specifications
| Interface | USB-Type-C |
| Charging Time | 2.5 hours |
Documentation
- UT-M25 User Manual
