RedArc Dual Input 40A In-Vehicle DC to DC Battery Charger

RedArc Dual Input 40A In-Vehicle DC to DC Battery Charger

Includes:1x In-Vehicle DC to DC Battery Charger – BCDC1240D

Details:The REDARC BCDC1240D In-vehicle Battery Charger is the next generation in REDARC’s DC to DC charging technology, with additional features that make it the most advanced dual battery charger on the market.

Featuring a Maximum Power Point Tracking (MPPT) solar regulator, the BCDC1240D will charge from both solar and the alternator simultaneously. With built-in‘Green Power Priority’it will select solar charging first, meaning less load on the alternator.

Suitable for 12 or 24-volt vehicle systems, the unit will also work with either standard or variable/smart alternators.

The BCDC1240D also comes with patented charging profiles, including a lithium charging profile. The ‘Dual’ input range will continue to charge all other types of batteries including AGM, GEL, standard lead acid and calcium.

As a guide, the BCDC1240D is used for battery bank sizes over 200AH. For smaller batteries of 75-200AH REDARC recommends theBCDC1225D.

The award-winning technology in the BCDC has been independently verified and tested to ensure battery life is maximised, charging your battery to a proven 100%.

Built in Australia and tested for our unique conditions, the DC to DC battery charger will work in the extreme heat of the Simpson Desert, up to 80C and can handle deep water crossings at Cape York water, dust and vibration are no match for this charger.

If you’re heading out into the bush and want to get there and back again safely you can trust REDARC.

Features– Separate DC and solar charging inputs– Maximises the performance and life of your auxiliary battery– Simultaneous DC and solar charging with Green Power Priority– Suits 12V/24V standard and variable voltage/smart alternators– Suitable for AGM, GEL, standard lead acid, calcium and Lithium (LiFePO4) batteries

Mounting BracketsIn addition to the use ofquality fuse kits, REDARC offer a range of vehicle-specificmounting bracketsfor our BCDC DC-DC Charger range. The 304 stainless steel bracket allows installation into the front of the vehicle for cooler airflow, ensuring optimal performance. They have been designed to fit existing mounting points in the vehicle.SpecificationsInput (Operating) Voltage: 9 – 32VDCOutput System Voltage: 12VDCMaximum Charging Voltage: 15.3VOutput Current Rating (Cont.): 40AInput Fuse Rating: 60AOutput Fuse Rating: 60AWarranty: 2 YearsStandby Current Draw: <100mAOutput Power: 600WLength (mm): 165Width (mm): 120Height (mm): 37Weight (kg): 1Type Approval: E-Mark
