PPWMTIP is an adapter that is plugged into PP products with 4mm banana plugs (such as THE MAESTRO/PP4/PP3/PP3EZ etc. The adapter can be set for the output 0-100% pulse width drive waveform by pressing the key. It is mainly used for such as automotive fan circuit detection, to find the part of the circuit failure, in order to replace and repair.
Features
5-100% Duty Cycle Adjustment
10A maximum continuous output
4mm Banana Jack in/out
Output PWM accuracy 2%
Operating Voltage range: 8-16VDC
Contents
Power Probe PWM adapter
Instruction Guide
