Overview
The MSO3000X-BND unlocks the entire library of serial bus analysis options for your MSO3000X Series oscilloscope in a single license automotive (CAN, CAN-FD, FlexRay, SENT, LIN), audio (Audio (I2S/LJ/RJ/TDM)), aerospace (MIL-STD-1553, ARINC 429), wireless/industrial (Manchester). One key, every protocol.
The bundle costs less than buying the included options separately. Future-proof your bench and eliminate procurement delays. The option is enabled by a software license keyed to the oscilloscope’s serial number and is permanent for the life of the instrument.
Key Features
- What’s Included 9 protocols with full trigger, decode, and search:
- CAN (Controller Area Network)
- CAN-FD
- FlexRay
- SENT (SAE J2716)
- LIN (Local Interconnect Network)
- Audio Serial Bus (I2S, LJ, RJ, TDM)
- MIL-STD-1553
- ARINC 429
- Manchester Encoding
- Bundle savings One bundle price covers every included option for considerably less than buying them separately.
- Single License Key One key unlocks all protocols. No managing separate licenses.
- Future-Proof Every protocol ready when you need it. No procurement delays.
- Lifetime License Activation activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- Multi-Domain Development Your product uses multiple bus types. The BND covers everything from day one.
- Test Lab Ready for Anything Serves clients across automotive, aerospace, and consumer electronics. Every protocol available without scrambling for licenses mid-project.
Compatibility
This option is compatible with all MSO3000X Series oscilloscopes: MSO3034X (350 MHz) and MSO3054X (500 MHz). The same capability is offered on other UNI-T oscilloscope families: MSO/UPO2000, MSO/UPO3000CS, MSO2000X, MSO3000HD, MSO5000HD, MSO7000X, MSO8000HD, UPO7000L.
Frequently Asked Questions
I only need two protocols. Is the bundle worth it?
Compare the combined individual price to the bundle price. The bundle often wins at just two or three protocols and future projects may need more.
Does BND include power analysis, AWG, or bandwidth upgrades?
No. BND covers serial bus protocols only. MSO3000X-AWG Arbitrary Waveform Generator option, MSO3000X-PWR Power Analysis Option are separate options.
How is this option activated?
The option is enabled by a software license keyed to the oscilloscope’s serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the instrument from a USB drive through the option-install menu. Refer to the oscilloscope’s user manual for the step-by-step procedure.
Is the license permanent, or does it require renewal?
The license is permanent a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
