SKU: 09.C338.11 / UPC: 8020584228036
Brembo 17-19 Honda Civic Type R Front Premium UV Coated OE Equivalent Rotor
Brembo 09.C338.11 UV coated rotors serve as direct replacements for 2017-2019 Honda Civic Type R front brakes, matching OE specifications. High carbon cast iron construction reduces noise and vibration while delivering consistent performance and driving comfort. A fixing screw kit ensures straightforward installation, and intelligent markings indicate part number and minimum thickness for maintenance.
Key Features
- UV Coating Solvent-free protection covers the entire disc, including braking surfaces, to prevent corrosion.
- High Carbon Cast Iron Minimizes noise and vibration for smoother, quieter braking.
- Fixing Screw Kit Includes all necessary hardware for simple, hassle-free installation.
- Intelligent Markings Displays part number and minimum thickness for easy inspection.
- OE Direct Replacement Meets or exceeds original equipment standards for perfect fit.
- Pad Pairing Recommendation Works with Brembo NAO/Ceramic or Low Met formulations for full braking restoration.
Specifications
| Detail | Value |
|---|---|
| Brand | Brembo |
| Type | Front Brake Rotor |
| Compatibility | 2017-2019 Honda Civic Type R |
| Diameter | 350 mm |
| Nominal Thickness | 25 mm |
| Minimum Thickness | 23 mm |
| Height | 60 mm |
| Weight | 26.46 lbs |
| Country of Origin | Italy |
| Warranty | 24 Month / 24,000 Mile Limited |
Whats Included
- 1 x Brembo UV Coated Front Brake Rotor
- Fixing Screw Kit with Hardware
Product Notes
- Replace rotors and pads together to restore braking performance.
- Sold individually. two required for front axle.
- Designed specifically for Honda Civic Type R models.
This Part Fits
| Year Range | Make | Model | Notes |
|---|---|---|---|
| 2017-2019 | Honda | Civic Type R | Front Brake |
Why Choose Brembo?
- Trusted braking brand worldwide.
- Environmentally friendly UV coating process.
- High carbon metallurgy for durability.
- Complete installation hardware provided.
Frequently Asked Questions
- Q: Does this rotor fit both left and right front positions?
- A: Yes, the design is symmetric for both sides.
- Q: What makes the UV coating different?
- A: It provides full corrosion resistance without solvents, protecting all surfaces.
- Q: Is this compatible with non-Type R Civic models?
- A: No, it is engineered for Type R 350 mm front rotors only.
Shipping & Handling
- Method: UPS Ground
- Availability: In stock ships same or next business day
- Packaging: Durable box 14.4 x 14.4 x 2.6 inches, 26.46 lbs
